Intel Core i5-12600K Box 10-Core LGA 1700 12th Gen CPU Processor

Product Description:

Intel Core i7-12700KF 12-Core LGA 1700 12th Gen CPU Processor

Power up your productivity, gaming, and content creation experiences by installing the Intel Core i7-12700KF 3.6 GHz 12-Core LGA 1700 Processor into your desktop computer system. Built using a Hybrid Core architecture with the Intel 7 process, this 12th generation desktop processor's 12 cores combine the performance of four Efficient-cores and eight 3.6 GHz Performance-cores. The low-voltage Efficient-cores handle background tasks for multitasking while the Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time to maximize performance. Additionally, this processor has a 5 GHz Turbo Boost Max 3.0 frequency with 25MB of cache for fast and reliable performance. The Core i7-12700KF also includes support for up to PCI Express 5.0 and dual-channel DDR5 memory at 4800 MHz to help run and multitask a variety of demanding applications. You can overclock this processor for even greater performance.

The Core i7-12700KF does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. Please note that a thermal solution NOT is included. The processor is compatible with Intel LGA 1700 socket motherboards and is backed

Hybrid Core Design

Background tasks are handled by the processor's Efficient-cores for multitasking while the Performance-cores provide the speed to handle high-end games and demanding applications.

Intel Thread Director

The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 20 threads are assigned to the right core at the right time.

PCIe 4.0 & 5.0

This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.

Intel Deep Learning Boost

Accelerates AI inference to improve performance for deep learning workloads.

Gaussian & Neural Accelerator 3.0

Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.

Specifications

Essentials

Download Specifications

Product Collection : 12th Generation Intel® Core™ i7 Processors

Code Name : Products formerly Alder Lake

Vertical Segment : Desktop

Processor Number  : i7-12700KF

Status : Launched

Launch Date : Q4'21

Lithography : Intel 7

Use Conditions : PC/Client/Tablet

CPU Specifications

Total Cores : 12

# of Performance-cores : 8

# of Efficient-cores : 4

Total Threads  : 20

Max Turbo Frequency  : 5.00 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency :  5.00 GHz

Performance-core Max Turbo Frequency : 4.90 GHz

Efficient-core Max Turbo Frequency  : 3.80 GHz

Performance-core Base Frequency : 3.60 GHz

Efficient-core Base Frequency : 2.70 GHz

Cache  : 25 MB Intel® Smart Cache

Total : L2 Cache12 MB

Processor Base Power : 125 W

Maximum Turbo Power : 190 W

Supplemental Information

Embedded Options Available : No

Memory Specifications

Max Memory Size (dependent on memory type) : 128 GB

Memory Types : Up to DDR5 4800 MT/s


                            Up to DDR4 3200 MT/s

Max # of Memory Channels : 2

Max Memory Bandwidth : 76.8 GB/s

Expansion Options

Direct Media Interface (DMI) Revision : 4.0

Max # of DMI Lanes : 8

Scalability : 1S Only

PCI Express Revision  : 5.0 and 4.0

PCI Express Configurations  :  Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes  : 20

Package Specifications

Sockets Supported  : FCLGA1700

Max CPU Configuration : 1

Thermal Solution Specification  : PCG 2020A

TJUNCTION : 100°C

Package Size : 45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator : 3.0

Intel® Thread Director : Yes

Intel® Deep Learning Boost (Intel® DL Boost)  : Yes

Intel® Optane™ Memory Supported : Yes

Intel® Speed Shift Technology : Yes

Intel® Turbo Boost Max Technology 3.0 : Yes

Intel® Turbo Boost Technology :  2.0

Intel® Hyper-Threading Technology :  Yes

Intel® Virtualization Technology (VT-x) :  Yes

Intel® Virtualization Technology for Directed I/O (VT-d) : Yes

Intel® VT-x with Extended Page Tables (EPT) :  Yes

Intel® 64 :  Yes

Instruction Set : 64-bit

Instruction Set  : Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States  : Yes

Enhanced Intel Speed : Step® Technology Yes

Thermal Monitoring Technologies  : Yes

Intel® Volume Management Device (VMD) : Yes

Security & Reliability

Intel® AES New Instructions : Yes

Secure Key : Yes

Intel® OS Guard : Yes

Execute Disable Bit :  Yes

Intel® Boot Guard : Yes

Mode-based Execute Control (MBE) : Yes

Intel® Control-Flow Enforcement Technology : Yes
