NZXT H5 Elite Edition ATX Mid Tower Case - White - CC-H51EW-01

NZXT H5 Elite Edition ATX Mid Tower Case - White

The H5 Elite features a tempered glass front panel and built-in RGB functionality to showcase various lighting components. With optimized thermal performance and intuitive cable management, the H5 Elite is an ideal chassis for most builds.

Fan Capacity

Fan mounts offer space for two 140mm fans on the front panel and two 120mm fans on the top panel.

Top: 2x 120mm

Front: 2x 140mm / 2x 120mm

Rear: 1x 120mm

Bottom: 1x 120mm

Radiator Capacity

The top panel offers space for a 240mm radiator and the front panel provides room for a 280mm radiator.

Specifications:-
KEY SPECS

Motherboard Support : Mini-ITX, Micro-ATX, ATX
Enclosure Type : Mid-Tower
Case Material : SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)


DIMENSIONS

Height : 464 mm (With Feet)
Width : 227 mm
Depth : 446 mm
Weight : 8.1 kg


COMPATIBILITY & CLEARANCE

Max CPU Cooler Clearance : Up to 165mm
Max GPU Clearance : Up to 365mm
Front Radiator Clearance : 45mm
Cable Management : Up to 23mm


FRONT I/O PORTS

USB 3.2 Gen 1 Type-A : 1
USB 3.2 Gen 2 Type-C : 1
Headset Audio Jack : 1


INCLUDED ACCESSORIES

Installation screws : 1
Cable ties : 10
RGB Lighting Controller : NZXT RGB Connector: 3 (Support up to 120 LEDs)


EXPANSION SLOTS

Standard : 7


DRIVE BAYS

2.5" : 1+1
3.5" : 1


FAN SUPPORT

Front : 2 x F Series RGB 140mm (Case Version) included
Top : 2 x 120mm
Rear : 1 x 120mm
Bottom : 1 x F Series Quiet 120mm (Case Version) included
Filters : All Air Intakes
RADIATOR SUPPORT
Front : Up to 280mm
Top : Up to 240mm
Rear : Up to 120mm


FAN SPECS

Model : F140 RGB Fan
Speed : 500 - 1800 RPM
Airflow : 24.85 - 89.48 CFM
Static Pressure : 0.94 - 3.39 mm-H2O
Noise : 20 - 32.5 dBA
Fan Connector : 4-pin


FAN SPECS

Model : F120Q Airflow Fan (Case Version)
Speed : 1200 ± 240 RPM
Airflow : 62.18 CFM
Static Pressure : 1.05 mm-H2O
Noise : 25.1 dBA
Fan Connector : 3-pin


Inside the Box

H5 Elite Case : 1
Front I/O split cables : 1
Brown box, PE bag, polyform, manual, accessory box & parts (including the screws) : 1
