NZXT H9 Flow Edition ATX Mid Tower Case - Black

The H9 Flow is designed to cool off powerful GPUs with its expansive thermal capabilities, featuring the capacity for ten fans and numerous 360mm radiator mounting options and the perforated top panel takes cooling even further.

GPU Capacity

The H9 Flow has 435mm of GPU clearance, offering room for the latest NVIDIA 40 Series and AMD 7000 Series cards.

Fan Capacity

The H9 Flow has room for 10 fans. With the capacity for 3x120mm fans on the side, 3 x 120mm or 2x140mm on the top and bottom, and 1 x120mm on the rear.

Radiator Capacity

The H9 Flow has room for up to a 360mm radiator on the top, bottom, or side, and up to a 120mm radiator on the rear.

Specifications:-
KEY SPECS

Motherboard Support : Mini-ITX, Micro-ATX, ATX
Enclosure Type : Mid-Tower
Case Material : SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)

DIMENSIONS

Height : 495mm (With Feet)
Width : 290mm
Depth : 466mm
Weight : 12.1 kg

COMPATIBILITY & CLEARANCE

Max CPU Cooler Clearance : Up to 165mm
Max GPU Clearance : Up to 435mm
PSU Clearance : 200mm
Cable Management : 91mm

FRONT I/O PORTS

USB 3.2 Gen 1 Type-A : 2
USB 3.2 Gen 2 Type-C : 1
Headset Audio Jack : 1

EXPANSION SLOTS

Standard : 7
Vertical : 0

FAN SUPPORT

Side : 3 x 120mm
Top : 3 x 120mm / 2 x 140mm
Bottom : 3 x 120mm / 2 x 140mm
Rear : 1 x 120mm
Filters : All Air Intakes

RADIATOR SUPPORT

Side : Up to 360mm with Push/Pull
Top : Up to 360mm
Bottom : Up to 360mm
Rear : Up to 120mm

FAN SPECS

Model : F120Q (Case Version)
Speed : 1200 ± 240RPM
Airflow : 62.18 CFM
Static : 1.05 mm - H2O
Noise : 25.1 dBA
Fan Connector : 3-pin

Inside the Box

H9 Flow Case : 1
Front I/O split cables : 1
120mm Quiet Airflow Fan (Case Version) : 4
Installation Accessories : 1
Manual
