NZXT N7 Z790 ATX Gaming Motherboard - Black

The N7 Z790 supports Intel's latest CPUs and has everything needed to build a modern system. The full black or white cover blends seamlessly within your build and includes optimally placed headers and built-in fan & lighting controls via NZXT CAM.

The Latest and Greatest

The N7 Z790 allows for a great look without sacrificing the build experience with an integrated rear I/O and optimally placed headers.

Stunning Craftsmanship

Build your dream system with a full metal cover that blends aesthetically with black or white cases for a seamless backdrop for your prized components.

Powerful Control

The N7 Z790 includes key features from the NZXT RGB and Fan Controller, allowing intuitive control of six RGB lighting channels and seven fan channels through NZXT CAM. Lighting accessories from all manufacturers are supported as well as 5V ARGB.

Specifications:-CPU & SOCKET

Intel® Socket LGA 1700 for Intel® 13th and 12th Generation Processors : Intel® Core™ Processors. Please refer to CPU support list.
Intel® Hybrid Technology : Supported
Turbo Boost Max 3.0 Technology : Supported
Intel® Thermal Velocity Boost (TVB) : Supported
Intel® Adaptive Boost Technology (ABT) : Supported


CHIPSET

Intel® : Z790


MEMORY

DIMM Slots : 4, DDR5 only
Max Memory Support : 128GB, DDR5
Memory Architecture : Dual-Channel
OC Frequency : 6000+(O.C.). Please refer to memory QVL.
Intel® Extreme Memory Profile (XMP) 3.0 : Supported


EXPANSION SLOTS

PCIe 5.0 ×16 slot (PCIEX16_1), supports ×16 mode : 1 (Supports NVMe SSD as boot disks)
PCIe 4.0 ×16 slots (PCIEX16_2 and PCIEX16_3), support ×4 mode : 2 (Supports NVMe SSD as boot disks)
PCIe 3.0 ×1 slots (PCIEX1_1 and PCIEX1_2)* : 2 (Supports NVMe SSD as boot disks)
M.2 Socket (Key E), supports Type 2230 Wi-Fi/BT PCIe Wi-Fi module and Intel® CNVio/CNVio2 : 1


STORAGE

M.2_1, Type 2242/2260/2280 (PCIe 4.0 ×4 mode) : 1
M.2_2, Type 2242/2260/2280/22110 (PCIe 4.0 ×4 mode) : 1
M.2_3, Type 2242/2260/2280 (PCIe 4.0 ×4 and SATA 6Gb/s mode) : 1
SATA 6Gb/s ports : 4
Intel® Volume Management Device (VMD) : Supported
NVMe SSD as boot disks : Supported


LAN

Realtek® : RTL8125BG 2.5G LAN


WIRELESS

Dual Band Wi-Fi 6E : Supported
Bluetooth : V5.2


AUDIO

Realtek®:ALC1220 Codec


REAR I/O

Wireless antenna SMA connectors : 2
HDMI™ port : 1
USB 2.0 : 2
USB 3.2 Gen 2x2 Type-C port : 1
USB 3.2 Gen 2 ports : 2
USB 3.2 Gen 1 ports : 3
Clear CMOS button : 1
LAN (RJ45) port : 1
Audio jacks : 5
Optical S/PDIF Out port : 1


INTERNAL I/O

24-pin ATX power connector : 1
8+4-pin ATX 12V power connector : 1
4-pin CPU_FAN connector : 1
4-pin AIO_PUMP connector : 1
4-pin SYS_FAN connectors : 5
NZXT RGB LED connectors : 4
5V ARGB LED connector : 2
USB 2.0 header (Up to 4 USB 2.0 ports) : 2
USB 3.2 Gen1 header (Up to 2 USB 3.2 Gen 1 ports) : 1
USB 3.2 Gen2x2 front panel header (For USB Type-C) : 1
Front panel audio connector : 1
Power button : 1
Reset button : 1
POST LEDs : 4


GENERAL

Operating System : Windows® 11/10 64-bit
Form Factor : ATX
